Mikrotik CCR2116-12G-4S+ v7 Router
The Mikrotik CCR2116-12G-4S+ v7 Router delivers unparalleled processing power for modern 10G networking environments. This device features a mighty 16-core Amazon Annapurna Labs Alpine CPU. Consequently, it eliminates the CPU limitations often found in high-traffic setups. You can handle massive BGP routing and complex firewall rules with ease. Furthermore, the Mikrotik CCR2116-12G-4S+ v7 Router supports Layer 3 Hardware Offloading for maximum efficiency. It includes twelve Gigabit Ethernet ports for extensive local connectivity. Additionally, four 10G SFP+ ports provide high-speed uplinks to your core network. Each port group has a dedicated connection to the switch chip. Therefore, you experience zero bottlenecks during heavy data transfers. The unit comes equipped with 16GB of high-speed DDR4 RAM. It also features a useful M.2 PCIe slot for SSD storage expansion. This capability is perfect for running Container applications on RouterOS v7. Moreover, the Mikrotik CCR2116-12G-4S+ v7 Router includes a dual-redundant power supply system. This setup ensures your business remains online even if one PSU fails. The cooling system uses four high-performance fans for stable operation. Specifically, it maintains peak performance in temperatures up to 60°C. To see if this unit fits your current rack, check our stock today. We recommend visiting the official Mikrotik product page for full compatibility details. Selecting the Mikrotik CCR2116-12G-4S+ v7 Router provides six times faster BGP performance than previous models. It is the professional choice for large ISPs and data centers. The rackmount chassis fits perfectly into a standard 1U space. Furthermore, the device is fully optimized for the latest RouterOS features. You can manage intricate Quality of Service (QoS) configurations effortlessly. In addition, the single-core performance has been increased by at least 15 percent. This improvement is vital for per-connection processing tasks. Consequently, your network latency stays low during peak hours. The Mikrotik CCR2116-12G-4S+ v7 Router is built for the future of 10G infrastructure. It combines raw utility with reliable enterprise-grade hardware. Finally, the included rackmount brackets make installation a simple process.
Key Features:
- Powerful CPU: 16-core ARMv8 64-bit processor at 2.0 GHz for exceptional routing performance.
- High-Speed Ports: 12 x Gigabit Ethernet ports and 4 x SFP+ 10G ports for flexible connectivity.
- Ample Memory: 16 GB DDR4 RAM and 1 GB NAND storage ensure smooth multitasking and high throughput.
- Advanced OS: Runs RouterOS v7 (Level 6 license) with full routing, firewall, and VPN capabilities.
- High Throughput: Designed for heavy data loads with improved packet processing efficiency.
- Cooling & Reliability: Passive cooling with intelligent fan control for quiet and stable operation.
- Rackmount Design: 1U rackmount chassis suitable for enterprise and data center installations.
- Energy Efficient: Optimized power consumption for 24/7 operation.
- Versatile Use: Ideal for ISPs, large enterprises, and backbone network routing.
| Specification | Details |
|---|---|
| Product Model | MikroTik CCR2116-12G-4S+ |
| CPU | 16-core ARMv8 64-bit (Altra Annapurna Labs) @ 2.0 GHz |
| CPU Architecture | ARM 64-bit |
| CPU Threads | 16 |
| RAM | 16 GB DDR4 |
| Storage | 1 GB NAND |
| Ethernet Ports | 12 × Gigabit Ethernet ports (RJ45) |
| SFP+ Ports | 4 × 10G SFP+ ports |
| Console Port | USB Type-C (console access) |
| Operating System | RouterOS v7 (License Level 6) |
| Switch Chip Model | Independent Ethernet interfaces (no switch chip) |
| Performance | Up to 100 Gbps total throughput |
| Max Power Consumption | 60 W (with attachments) |
| Power Supply | Dual redundant hot-swappable power supplies |
| Cooling Type | Passive with intelligent fan control |
| Dimensions | 443 × 199 × 44 mm (1U rackmount) |
| Operating Temperature | -20°C to +60°C |
| Certification | CE, EAC, ROHS |
| MTBF (Mean Time Between Failures) | Approximately 200,000 hours (25 years) |
| Use Case | Core routing, ISP backbone, enterprise networks |
