The TP-Link / EAP773 / BE11000 Tri-Band Wi-Fi 7 Access Point represents the cutting edge of wireless networking technology for high-density enterprise environments. Specifically, this device leverages the advanced Wi-Fi 7 standard to provide an aggregate throughput of up to 11 Gbps across three distinct frequency bands. Furthermore, the inclusion of a 10G Ethernet port ensures that your wired backhaul never becomes a bottleneck for wireless performance. Therefore, users can enjoy lightning-fast connectivity for bandwidth-intensive tasks like 8K streaming and large-scale cloud operations. You can check our stock to see if this revolutionary hardware is available for your next network upgrade. Moreover, the Multi-Link Operation (MLO) technology allows compatible devices to transmit data across multiple bands simultaneously. Consequently, network latency is significantly reduced while overall reliability is increased for critical business applications. Specifically, the ultra-thin design allows for a sleek ceiling mount installation that blends seamlessly into professional office aesthetics. This TP-Link / EAP773 / BE11000 Tri-Band Wi-Fi 7 Access Point also features 320 MHz bandwidth on the 6 GHz band for maximum data density. Additionally, it supports over 380 concurrent clients, making it ideal for busy retail spaces or large corporate headquarters. Many administrators value the Omada SDN integration which allows for centralized cloud management of the entire network. Furthermore, the device includes advanced security features such as WPA3 encryption and rogue AP detection to protect sensitive data. According to the official TP-Link website, this model utilizes 4K-QAM to pack more data into every signal. Therefore, it provides a 20% higher data transmission rate compared to previous generations. The TP-Link / EAP773 / BE11000 Tri-Band Wi-Fi 7 Access Point is powered via PoE++ for a simplified, single-cable installation process. Specifically, it is backward compatible with older Wi-Fi standards to ensure all your existing devices remain connected. High-performance networking requires hardware that can scale with your business growth. Consequently, the TP-Link / EAP773 / BE11000 Tri-Band Wi-Fi 7 Access Point is the ultimate choice for future-proofing your wireless infrastructure.
Key Features:
- BE11000 Tri-Band Speeds: Delivers up to 11 Gbps aggregate throughput for buffer-free performance.
- 10G Multi-Gigabit Port: Maximizes Wi-Fi 7 potential with a high-speed 10 Gbps wired uplink.
- Wi-Fi 7 Technology: Utilizes MLO, 320 MHz bandwidth, and 4K-QAM for ultra-low latency.
- 380+ Concurrent Clients: High-capacity design built for demanding, high-density environments.
- Omada SDN Integration: Enables centralized cloud management and zero-touch provisioning.
| Category | Specification |
|---|---|
| Model | EAP773 |
| Wireless Standard | IEEE 802.11 a/b/g/n/ac/ax/be |
| Frequency Bands | Tri-band: 2.4 GHz / 5 GHz / 6 GHz |
| Maximum Data Rates | • 2.4 GHz: 574 Mbps • 5 GHz: 4320 Mbps • 6 GHz: 5760 Mbps |
| Channel Bandwidth (6 GHz) | Up to 320 MHz |
| High-Density / Multi-User Features | MLO (Multi-Link Operation), 4K-QAM, HE320, OFDMA, MU-MIMO, BSS Coloring, Load Balancing, Airtime Fairness |
| Wireless Clients Capacity | Up to 128 clients per band (2.4 / 5 / 6 GHz) |
| Transmit Power | • < 25 dBm (2.4 GHz) • < 25 dBm (5 GHz) • < 23 dBm (6 GHz) |
| Antenna | Internal antennas: • 2.4 GHz: 2 × ~3.0 dBi (or 4.0 dBi in some specs) • 5 GHz: 2 × ~3.0 (or 5.0) dBi • 6 GHz: 2 × ~3.0 (or 5.0) dBi |
| Ethernet / Uplink | 1 × 10 Gbps RJ-45 Ethernet Port |
| Power Supply | • 802.3bt PoE (or PoE+) • 12 V DC, 2.5 A (DC adapter not included) |
| Power Consumption | • ~25.94 W (PoE, full) • ~22.57 W (DC) |
| Mounting | Ceiling / Wall mounting (kits included) |
| Bluetooth | 1 × Bluetooth 5.2 (4.0 dBi) |
| Concurrent SSIDs | Up to 24 SSIDs (8 per band) |
| Security | WPA-Personal/Enterprise, WPA2, WPA3, Captive Portal, Access Control, VLAN, Rogue AP Detection, Isolation |
| Management | Centralized via Omada SDN: Cloud-based controller, Hardware controller (OC200/OC300), Software controller |
| Roaming / Mesh | Seamless Roaming (802.11k/v/r), Omada Mesh support |
| Operating Temperature | 0 °C – 40 °C |
| Dimensions | 220 × 220 × 32.5 mm (8.7″ × 8.7″ × 1.3″) |
| Certifications | CE, FCC, RoHS, IC |
