The UniFi U7 Pro Max is Ubiquiti’s high-end Wi-Fi 7 (802.11be) access point designed for demanding, high-density indoor environments. It is part of UniFi’s Flagship line of ceiling/wall-mount APs. It supports tri-band operation (2.4 GHz, 5 GHz, 6 GHz), comes with 8 spatial streams, and includes a dedicated spectral scanning engine to monitor radio interference and dynamically optimize channel usage. It is typically powered via PoE+ (802.3at) and offers a 1 / 2.5 GbE RJ45 port for data backhaul.
Key Features
- Support for Wi-Fi 7 (802.11be) with tri-band operation (2.4GHz, 5GHz & 6GHz) — ensures future-proof wireless capability.
- Up to 8 spatial streams (2×2 on 2.4GHz, 4×4 on 5GHz, 2×2 on 6GHz) for high client/data capacity.
- Very high aggregated throughput: e.g., approx. 8.6 Gbps on 5GHz + ~5.7 Gbps on 6GHz + ~688 Mbps on 2.4GHz in ideal conditions.
- Built-in real-time spectral scanning / engine for interference detection, channel optimisation and improved RF performance.
- Multi-gig wired uplink support — 1 × RJ-45 port supporting up to 2.5 GbE to match higher wireless speeds.
- PoE+ (IEEE 802.3at) power support — simplifies installation and cabling by using a single cable for data + power.
- Designed for high-density deployments: supports 500+ concurrent clients and covers large indoor areas (approx. up to 160 m²) under ideal conditions.
- Wall or ceiling mountable, with mounting kit included; sleek form factor suited to modern indoor spaces.
- Full compatibility with the UniFi management ecosystem (controller/OS) for centralised monitoring, configuration and analytics.
- Enterprise-grade security and features: e.g., support for WPA3, PPSK, guest isolation, VLANs, advanced QoS.
- Future-ready features: includes support for Multi-Link Operation (MLO) and very wide channel widths (320 MHz) for accelerated performance on WiFi 7 clients
Technical Specification
| Specification | Details |
|---|---|
| Model | U7-Pro-Max |
| Wi-Fi Standard | 802.11a / b / g / n / ac / ax / be (Wi-Fi 7) |
| Frequency Bands | 2.4 GHz, 5 GHz, 6 GHz |
| Spatial Streams (MIMO) | – 2.4 GHz: 2×2 – 5 GHz: 4×4 – 6 GHz: 2×2 |
| Max Data Rates (Theoretical) | – 2.4 GHz: 688 Mbps (BW 40) – 5 GHz: 8.6 Gbps (BW 240) – 6 GHz: 5.7 Gbps (BW 320) |
| Transmit Power (Max) | – 2.4 GHz: 23 dBm – 5 GHz: 29 dBm – 6 GHz: 23 dBm |
| Antenna Gain | – 2.4 GHz: 4 dBi – 5 GHz: 6 dBi – 6 GHz: 5.9 dBi |
| Network Interface / Uplink | 1 × RJ-45, supports 1 / 2.5 GbE |
| Power Method | PoE+ (IEEE 802.3at) |
| Supported Voltage | 44 – 57 V DC |
| Max Power Consumption | ~ 25 W (some sources list ~22 W) |
| LED / Button | LED: White/blue Button: Factory Reset |
| Mounting Options | Ceiling or Wall (mounting kit included) |
| Dimensions | Diameter: 206 mm, Height: 46 mm (Ø 206 × 46 mm) |
| Weight | 680 g (1.5 lb) |
| Operating Temperature | -30 °C to 60 °C (-22 °F to 140 °F) |
| Operating Humidity | 5% to 95%, non-condensing |
| Certifications | CE, FCC, IC |
| Concurrent Clients | Supports 500+ devices |
| Wireless Security | WPA-PSK, WPA-Enterprise (WPA / WPA2 / WPA3 / |
| BSSID / SSIDs | Up to 8 BSSIDs per radio |
| VLAN Support | 802.1Q VLAN tagging supported |
| Advanced QoS | Per-user rate limiting |
| Guest Traffic Isolation | Supported |
| Required UniFi Network Version | Version 8.2.93 or later (for spectral analysis) |
